HF Multi-Band Beams - High Power
CLASSIC "CL" SERIES
In order to give hams a choice in beam matching systems and an antenna featuring maximum gain with increased bandwidth, we devised the matching method used on the Classic antennas - the patented Balanced Capacitive Matching. For more information on the Classic feed system please see our FAQ section.
"TRIED & TRUE" The Classic antennas featuring the patented balanced capacitive matching.
As with all Mosley antennas, your elements and boom pieces are all pre-drilled and color coded, which makes assembly quick and easy.
Our hardware is made of the best grade of stainless steel and our tubing is aircraft grade drawn aluminum. The warranty on the CL line is two year against any defects of material or workmanship. Have a CL and want to upgrade or add other bands? SEE CONVERSION KITS
SIGNAL MASTER MULTI-BAND SERIES HF BEAMS
The Signal Master multi band series, heavy duty, rugged construction, and optimized for performance.
As with all Mosley antennas, pieces are all pre-drilled and color coded, which makes assembly quick and easy.
Our hardware is made of the best grade of stainless steel and our tubing is aircraft grade drawn aluminum.
TRAP MASTER SERIES HF BEAMS - PROVEN DESIGNS since 1957
The Trap Master series, still the most copied, broadband, multi-band beams made!
Rugged construction and designed for the amateur with a limited space and a tight budget. The Trap Master series addresses everyone's needs from power handling capabilities to frequency coverage. The great feature about the Trap Master series is you can add other frequencies or even add more elements for better performance. SEE CONVERSION KITS
As with all Mosley antennas, pieces are all pre-drilled and color coded, which makes assembly quick and easy. Our hardware is made of the best grade of stainless steel and our tubing is aircraft grade drawn aluminum.
"PRO" SERIES
Automatic band switching by means of high-impedance resonant trap circuits.
There are those out there who have been trying to copy and design a version of the PRO for the last 40 years. As with the copied TA-33, the TA-33 is still the best performing, durable, 14 foot tri-band beam made. Like the TAs, the PROs are the best performing, reliable and cost effective multi frequency antennas on the market.
Regardless of what our competitors sell to compete with the PROs, the PRO series offers the best all around beams in the industry! The PRO's offer the Ham radio community the most complete, cost effective and varied product line anywhere in the world.
These PRO's have been "Hurricane" tested over the past 4 decades. The PROs have been through some of the worst ice storms ever seen in the US. Regardless of the environment the PROs are rugged, stable, and reliable year after year.
If you are looking for an antenna with excellent performance which is trouble free and a great investment, then all you have to do is remember the name "Mosley". Predrilled and color coded for ease of assembly with quality materials and workmanship to insure a long life. Have a PRO and want to upgrade? SEE CONVERSION KITS
Model
CL-33-M
CL-33-M WARC
CL-36-M
CL-39-M
Band Coverage MHz
28, 21, 14
28, 24, 21, 18, 14
28, 21, 14
28, 21, 14
Description
Tri-band , 3 element beam, 18 foot boom.
5-band, 4 element beam, 18 foot boom.
Tri- band, 6 element beam, 24 foot boom.
Tri-band, 9 element beam, 40 foot boom.
Model
PRO-57-B
PRO-57-B-30
PRO-57-B-40
PRO-67-B
PRO-67-B-30
PRO-67-C
PRO-95
PRO-96
PRO-96-S
Band Coverage MHz
28, 24, 21, 18, 14
28, 24, 21, 18, 14, 10
28, 24, 21, 18, 14, 7
28, 24, 21, 18, 14, 7
28, 24, 21, 18, 14, 10
28, 24, 21, 18, 14,10, 7
28, 24, 21, 18, 14
28, 24, 21, 18, 14, 7
28, 24, 21, 18, 14, 10, 7
Description
5-band, 7 element beam, 24 foot boom.
6-band, 7 element beam, 24 foot boom.
6-band, 7 element beam, 24 foot boom.
6-band, 7 element beam, 24 foot boom.
6-band, 7 element beam, 24 foot boom.
7-band, 7 element beam, 24 foot boom.
5-band, 9 element bean, 36 foot boom.
6-band, 9 element beam, 36 foot boom.
7-band, 11 element beam, 48 foot boom.
Band Coverage MHz
18, 14, 7
Description
Tri-band, 3 element heavy duty beam.
Model
MP-32
MP-33
MP-33 WARC
TA-31-M
TA-32-M
TA-33-M
TA-33-M WARC
TA-34-XL
TA-34-XL WARC
TA-53-M
TA-63-N
TA-54-XL
TA-54-XLN-6
TW-21-M
TW-22-M
TW-23-M
TW-24-XL
TW-31-XL
TW-32-XL
TW-33-XL
TW-34-XL
Band Coverage MHz
28, 21, 14
28, 21, 14
28, 24, 21, 18, 14
28, 21, 14
28, 21, 14
28, 21, 14
28, 24, 21, 18, 14
28, 21, 14
28, 24, 21, 18, 14
28, 24, 21, 18, 14
50, 28, 24, 21, 18, 14
28, 24, 21, 18, 14
50, 28, 24, 21, 18, 14
24, 18
24, 18
24, 18
24, 18
24, 18, 10
24, 18, 10
24, 18, 10
24, 18, 10
Description
3-band, 2 element light weight, high power beam.
3-band, light weight, high power beam.
5-band, light weight, high power beam.
Tri-band rotatable dipole.
Tri-band 2 element beam, 7 ft. boom.
Tri-band, 3 element beam, 14 ft. boom.
5-band, 4 element beam, 14 ft. boom.
Tri-band, 4 element beam, 21 ft. boom.
5-band, 5 element beam, 21 ft. boom.
5-band, 4 element beam, 14 ft. boom.
6-band, 6 element beam, 14 ft. boom.
5-band, 5 element beam, 21 ft. boom.
6-band, 7 element beam, 21 ft. boom.
WARC, Dual-band, rotatable dipole.
WARC, Dual-band, 2 element beam.
WARC, Dual-band, 3 element beam.
WARC, Dual-band, 4 element beam.
WARC, Tri-band, rotatable dipole.
WARC, Tri-band, 2 element bean, 12 ft. boom.
WARC, Tri-band, 3 element beam, 18 ft. boom.
WARC, Tri-band, 4 element beam, 24 ft. boom.
